Kozy Chaska29 Gas Insert

Description

Features:

• Comes in Log, Glass or Rock media
• Viewing Area: 25-7/8″ x 12-5/8″
• BTU (Log & Rock) 30,000 (Glass) 25,500 (MV) 28,500
• Electronic Ignition Pilot System
• Co-Linear Air Duct –Accepts 3” Combustion Air / 3” Exhaust
• Ceramic Glass
• Fan Kit
• Standard Ember Light Kit
• Certified to ANSI Z21.88 Vented Gas Heater

• Log and Rock
  • ENERGUIDE P.4 NG/LP | 72.27%/72.36%
  • Steady State NG/LP | 74%/74%
  • AFUE % NG/LP | 71%/72.12%
• Glass
  • ENERGUIDE P.4 NG/LP | 60.8%/63.21%
  • Steady State NG/LP |72.21%/72.26%
  • AFUE % NG/LP | 66.62%/66.09%
• MV
  • ENERGUIDE P.4 NG/LP |71.26%/71.33%
    Steady State NG/LP | 74%/74%
    AFUE % NG/LP |71%/72.12%
• Efficiencies Glossary:
  • P.4 Efficiency (ENERGUIDE) is an efficiency rating more recognized in Canada to measure annual fireplace efficiency.
  • Steady State Efficiency is a measure of how efficiently your fireplace converts fuel to heat once it is warmed up and operating at a steady temperature.
  • Annual Fuel Utilization Efficiency (AFUE) is a measurement of the fireplace’s ability to convert fuel to heat over a longer period of time including the cycling on and off time period.

Design Standard Features

• Black Enamel Refractory
  • Standard on Chaska 29 Rock and Chaska 29 Glass only
• Ember Light Kit
  • Standard on Chaska 29 Log and Chaska 29 Rock only
• Accent Light Kit
  • Standard on Chaska 29 Glass only
• Screen Front
  • For options and pictures, look at the Chaska brochure under the Resources tab.

  Required Design Features

• Glass Media Kit
  • For options and pictures, look at the Chaska brochure under the Resources tab.
• Screen Front
  • For options and pictures, look at the Chaska brochure under the Resources tab.

Optional Features:

• Black Enamel Lining
  • Optional for Chaska 29 Log

Required for Installation:

• 1 Piece Shroud ( Standard or custom size)
